Breakout Automatic Sliding Doors

Breakout Automatic Sliding doors are a specialized type of sliding door designed to provide a secure and efficient exit in emergency situations. They are typically installed in commercial buildings, such as offices, retail spaces, and industrial facilities.

These doors feature a unique breakout mechanism that allows the sliding panels to pivot and swing open like traditional doors when pushed from the inside, ensuring a wide and immediate exit path during emergencies. Breakout automatic sliding doors are ideal for evacuation routes, complying with international safety standards while maintaining the aesthetic and functional benefits of regular sliding doors. They combine convenience, automation, and emergency functionality, making them an essential choice for buildings where both accessibility and safety are a priority.

Emergency Exit: They can be quickly and easily opened from the inside in case of an emergency.
Photocell Sensors: These doors are equipped with photocell sensors that automatically detect movement and open the door when necessary.
Sliding Mechanism: The sliding mechanism allows the door to be opened without requiring excessive force.
Durability: Breakout Automatic Sliding doors are built to withstand heavy use and harsh conditions.

Model LVX-SB2, LVX-SB4, LVX-SB6 Breakout Automatic Sliding Doors

Power Supply	220 V/AC±10% – 50 Hz.
Motor	24V DC
Wing	2 Leaves – 4 Leaves – 8 Leaves
Control Drive	Microprocessor based LED control unit
Partial Opening Function	Digital Adjusted for distance
Opening Speed	15–45 cm/s
Closing Speed	5–43 cm/s
Passage Opening Height (max)	2500 mm
Passage Opening Width (max)	2000 mm
Max Leaf Weight – Single Leaf	130 kg. (1×130 kg/leaf)
Max Leaf Weight – Double Leaf	240 kg. (2×120 kg/leaf)
Safety System	3H-IR14 Sensor
Leaf Safety	Robust triple pulley system with non-falling rail and secure Leaf mechanism
Programmer Functions	Manual, Automatic, Close, Open, One or Two directional, Partial opening
Self Adjustment Feature	Open / Closed
